Name: SO 42121
SKU: 41033

Vis alle mål +

Artikel nummer	d	R	bar	M	SW1/SW2	SW3	L1/L2	e	z1/z2
0182101068	4	3/8	125	10 x 1	12/7	17	23,5/29	3.4	16/19
0182101100	6	1/8	250	10 x 1	12/10	12	23,5/26	4.5	16/19
0182101110	6	1/4	250	10 x 1	12/10	14	23,5/30	4.5	16/20
0182101120	6	3/8	250	10 x 1	12/10	17	23,5/29	4.5	16/19
0182101125	6	1/2	250	10 x 1	12/10	22	23,5/32	4.5	16/18
0182101160	8	1/8	150	12 x 1	14/10	14	26/28	5	18/21
0182101170	8	1/4	150	12 x 1	14/10	14	26/32	6.5	18/22
0182101180	8	3/8	150	12 x 1	14/10	17	26/32	6.5	18/22
0182101270	10	1/4	125	14 x 1	17/14	17	31,5/34,5	8.5	21,5/24,5
0182101280	10	3/8	125	14 x 1	17/14	17	31,5/34,5	8.5	21,5/24,5
0182101285	10	1/2	100	14 x 1	17/14	22	31,5/36,5	8.5	21,5/25,5
0182101380	12	1/4	100	16 x 1	19/17	19	32,5/36,5	8.5	21,5/26,5
0182101390	12	3/8	100	16 x 1	19/17	19	32,5/36,5	10.5	21,5/26,5
0182101400	12	1/2	100	16 x 1	19/17	22	32,5/39,5	10	21,5/25,5
0182101850	28	1	16	36 x 2	41/32	41	58,5/65	24	39/48
0182101944	35	1 1/4	16	42 x 2	50/41	50	67/73	31	40/59

Datablad

Produktblad

SO 42121
