| TREL17-RC-063-050 |
|
63x50 | SDR17 | 3.8 | 100 | 213 | 3 | 60 | 56 |
|
| TREL17-RC-075-050 |
|
75x50 | SDR17 | 4.5 | 111 | 260 | 3 | 72.5 | 56 |
|
| TREL17-RC-075-063 |
|
75x63 | SDR17 | 4.5 | 117 | 255 | 3.8 | 70 | 63 |
|
| TREL17-RC-090-063 |
|
90x63 | SDR17 | 5.4 | 137 | 264 | 3.8 | 79 | 66 |
|
| TREL17-RC-090-075 |
|
90x75 | SDR17 | 5.4 | 138 | 272 | 4.5 | 73 | 68 |
|
| TREL17-RC-110-063 |
|
110x63 | SDR17 | 6.6 | 156.5 | 305 | 3.8 | 86.5 | 65 |
|
| TREL17-RC-110-075 |
|
110x75 | SDR17 | 6.6 | 152 | 307 | 4.5 | 83 | 68 |
|
| TREL17-RC-110-090 |
|
110x90 | SDR17 | 6.6 | 155 | 312 | 5.4 | 84 | 79 |
|
| TREL17-RC-125-063 |
|
125x63 | SDR17 | 7.4 | 170 | 350 | 3.8 | 110 | 70 |
|
| TREL17-RC-125-090 |
|
125x90 | SDR17 | 7.4 | 170 | 348 | 5.4 | 109 | 83.5 |
|
| TREL17-RC-125-110 |
|
125x110 | SDR17 | 7.4 | 167 | 340 | 6.6 | 90 | 83 |
|
| TREL17-140-075 |
|
140x75 | SDR17 | 8.3 | 177 | 390 | 4.5 | 104 | 77 |
CAD/Step
|
| TREL17-RC-160-063 |
|
160x63 | SDR17 | 9.5 | 172.5 | 340 | 3.8 | 97 | 67 |
|
| TREL17-RC-160-075 |
|
160x75 | SDR17 | 9.5 | 179 | 344 | 4.5 | 101 | 76 |
|
| TREL17-RC-160-090 |
|
160x90 | SDR17 | 9.5 | 177 | 343 | 5.4 | 100 | 80 |
|
| TREL17-RC-160-110 |
|
160x110 | SDR17 | 9.5 | 200 | 394 | 6.6 | 100 | 86 |
|
| TREL17-RC-180-090 |
|
180x90 | SDR17 | 10.7 | 200 | 420 | 5.4 | 136 | 97 |
|
| TREL17-180-110 |
|
180x110 | SDR17 | 10.7 | 230 | 460 | 6.6 | 117 | 98 |
CAD/Step
|
| TREL17-RC-180-160 |
|
180x160 | SDR17 | 10.7 | 204 | 412 | 9.5 | 105 | 94 |
|
| TREL17-RC-200-063 |
|
200x63 | SDR17 | 11.9 | 225 | 550 | 3.8 | 134 | 80 |
|
| TREL17-RC-200-090 |
|
200x90 | SDR17 | 11.9 | 225 | 550 | 5.4 | 134 | 95 |
|
| TREL17-RC-200-110 |
|
200x110 | SDR17 | 11.9 | 240 | 550 | 6.6 | 134 | 103 |
|
| TREL17-RC-200-125 |
|
200x125 | SDR17 | 11.9 | 245 | 550 | 7.4 | 134 | 110 |
|
| TREL17-RC-200-160 |
|
200x160 | SDR17 | 11.9 | 270 | 550 | 9.5 | 134 | 114 |
|
| TREL17-225-063 |
|
225x63 | SDR17 | 13.4 | 245 | 524 | 5.8 | 130 | 68 |
CAD/Step
|
| TREL17-RC-225-075 |
|
225x75 | SDR17 | 13.4 | 226 | 440 | 4.5 | 120 | 75 |
|
| TREL17-RC-225-090 |
|
225x90 | SDR17 | 13.4 | 224 | 440 | 5.4 | 120 | 79 |
|
| TREL17-RC-225-110 |
|
225x110 | SDR17 | 13.4 | 226 | 439 | 6.6 | 120 | 85 |
|
| TREL17-RC-225-160 |
|
225x160 | SDR17 | 13.4 | 246 | 486 | 9.5 | 120 | 98 |
|
| TREL17-RC-225-180 |
|
225x180 | SDR17 | 13.4 | 280 | 554 | 10.7 | 132 | 135 |
|
| TREL17-RC-250-110 |
|
250x110 | SDR17 | 14.8 | 245 | 625 | 6.6 | 148 | 86 |
|
| TREL17-RC-250-160 |
|
250x160 | SDR17 | 14.8 | 270 | 625 | 9.5 | 148 | 100 |
|
| TREL17-RC-250-200 |
|
250x200 | SDR17 | 14.8 | 290 | 625 | 11.9 | 148 | 116 |
|
| TREL17-280-110 |
|
280x110 | SDR17 | 16.6 | 326 | 653 | 6.6 | 126 | |
CAD/Step
|
| TREL17-280-160 |
|
280x160 | SDR17 | 16.6 | 280 | 642 | 9.5 | 146 | 118 |
CAD/Step
|
| TREL17-RC-315-090 |
|
315x90 | SDR17 | 18.7 | 290 | 545 | 5.4 | 170 | 90 |
|
| TREL17-RC-315-110 |
|
315x110 | SDR17 | 18.7 | 290 | 546 | 6.6 | 170 | 100 |
|
| TREL17-RC-315-160 |
|
315x160 | SDR17 | 18.7 | 310 | 575 | 9.5 | 170 | 120 |
|
| TREL17-RC-315-200 |
|
315x200 | SDR17 | 18.7 | 331 | 640 | 11.9 | 170 | 129.5 |
|
| TREL17-RC-315-225 |
|
315x225 | SDR17 | 18.7 | 335 | 638 | 13.4 | 170 | 145 |
|
| TREL17-RC-315-250 |
|
315x250 | SDR17 | 18.7 | 333 | 670 | 14.8 | 170 | 150 |
|
| TREL17-RC-355-160 |
|
355x160 | SDR17 | 21.1 | 325 | 874 | 9.5 | 188 | 103 |
CAD/Step
|
| TREL17-RC-355-200 |
|
355x200 | SDR17 | 21.1 | 350 | 874 | 13.4 | 188 | 125 |
|
| TREL17-RC-355-250 |
|
355x250 | SDR17 | 21.1 | 360 | 874 | 14.8 | 188 | 134 |
|
| TREL17-RC-400-110 |
|
400x110 | SDR17 | 23.7 | 330 | 940 | 6.6 | 198 | 87 |
|
| TREL17-RC-400-160 |
|
400x160 | SDR17 | 23.7 | 350 | 940 | 9.5 | 198 | 103 |
|
| TREL17-RC-400-200 |
|
400x200 | SDR17 | 23.7 | 365 | 940 | 11.9 | 198 | 117 |
|
| TREL17-RC-400-225 |
|
400x225 | SDR17 | 23.7 | 375 | 940 | 13.4 | 198 | 125 |
|
| TREL17-RC-400-315 |
|
400x315 | SDR17 | 23.7 | 415 | 940 | 18.7 | 198 | 155 |
|
